Monel alloy K500 Material

GB JIS UNS W.Nr
NS321 NW5500 N05500 2.4375
Executive standard (ASTM)(ASME)(AMS)(JIS)(DIN)(GB)
Surface: Mill;HL;Polish;Mirror;NO.4;Pvd…..
Tchnology: Solution Treatment;Annealing
MOQ: 200KG
Payment Term: T/T;L/C;WesternUnion;Paypal
Delivery Time: 7-15days upon receipt of the deposit
Package: Standard Expot Packing or As Customers Requirement
Processing form:



Home >> Products >>

Monel alloy K500 Material

Product Description:

Product Details:Monel alloyK500 coil; Monel alloy K500 strip Monel alloy K500 plate; Monel alloy K500 sheets; Monel alloy K500 tube; Monel alloy K500 pipe; Monel alloy K500 flat; Monel alloy K500 bar
11

Stainless Steel Details

Chemical composition
C Si Mn Cu S Ni Fe Ti Al P

0.18

0.50

1.50

27.00-

33.00

0.01

63.00

0.50-

2.00

0.35-

0.85

2.00-

3.15

0.02



Mechanical Property
T.S(Mpa)≥ YS(Mpa)≥ EL(%)≥ HB
935/1275 655/1103 10/20 255/370



Chemical composition
C Si Mn Cu S Ni Fe Ti Al P

0.18

0.50

1.50

27.00-

33.00

0.01

63.00

0.50-

2.00

0.35-

0.85

2.00-

3.15

0.02



Mechanical Property
T.S(Mpa)≥ YS(Mpa)≥ EL(%)≥ HB
935/1275 655/1103 10/20 255/370



Stainless Steel Introduce

Monel K500 Monel alloy is a high-strength nickel-copper alloy with excellent corrosion resistance. Its main components are nickel and copper, and it also contains a small amount of beneficial elements such as aluminum, iron, and titanium. This alloy not only has corrosion resistance, but also has excellent mechanical properties, high strength, hardness and toughness, and can withstand high temperature, high pressure and corrosion in marine environments. Monel K500 alloy is widely used in marine and subsea oil and gas industry, machinery manufacturing, aerospace and other fields. Compared with other nickel-copper alloys, Monel K500 alloy is more corrosion-resistant. It can resist the erosion of nitric acid, seawater, alkaline solution and other media, and can also maintain stable performance under high temperature and high pressure conditions. Due to its low magnetic properties, Monel K500 alloy is also widely used in the electrical and electronic industries. In addition, it also has good weldability and processing performance, and can be formed and manufactured by various methods such as casting, forging, and cold working, so as to meet the manufacturing needs of complex workpieces in different industrial fields. In general, Monel K500 alloy has good corrosion resistance, high mechanical strength, excellent stability and comprehensive performance, and is a very excellent high-performance alloy material. With the continuous development and innovation of science and technology, Monel K500 alloy has a very broad application prospect in the future, and will bring more benefits to human production and life.

American standard designation: UNS N05500, Specifications: ASTM B865, ASTM B164, ASTM B127, ASTM B165, ASTM B564, ASTM B865, ASTM B366, ASTM B865, AMS 4676, AMS 4676, AMS 4677, AMS 4677, AMS 4678, AMS 4678, AMS 4679, AMS 4679.

German standard designation: W.Nr. 2.4375, Specifications: DIN 17743, DIN 17750, DIN 17752, DIN 17753, DIN 17754.

Japanese standard designation: JIS NW5500, Specifications: JIS G4902, JIS G4903, JIS G4904, JIS G4905, JIS G4906, JIS G4907.

Chinese standard designation: NS321, Specifications: GB/T 2054, GB/T 2055, GB/T 2056, GB/T 2057, GB/T 2058, GB/T 2059, GB/T 2060, GB/T 2061.



Application fields

Monel K500 alloy not only has excellent mechanical properties such as high strength, corrosion resistance, and non-magnetic properties, but also has the same corrosion resistance as Monel 400. It can be used as a pump shaft material, and is suitable for working under harsh geological mining conditions of high-sulfur and high-wax oil layers. Since the alloy has no plastic-brittle transition temperature, it is very suitable for various low-temperature equipment. This alloy is mainly used for pump shafts and valve stems, conveyor scrapers, oil well drill rings, elastic parts, valve pads, etc. Suitable for petroleum, chemical, shipbuilding, pharmaceutical, electronic sectors.

Monel K500 alloy not only has excellent mechanical properties such as high strength, corrosion resistance, and non-magnetic properties, but also has the same corrosion resistance as Monel 400. It can be used as a pump shaft material, and is suitable for working under harsh geological mining conditions of high-sulfur and high-wax oil layers. Since the alloy has no plastic-brittle transition temperature, it is very suitable for various low-temperature equipment. This alloy is mainly used for pump shafts and valve stems, conveyor scrapers, oil well drill rings, elastic parts, valve pads, etc. Suitable for petroleum, chemical, shipbuilding, pharmaceutical, electronic sectors.
